Technical information DAL Pulse Drive
The driver circuit technology of outputting our original super-high-speed and high-current pulses.
Simulates driving with an actual LiDAR loaded. Realizes the PLD operation infinitely close to the actual pulse shape.
| No. | Variation | Specs & features | DPLT | DBLT | DLTS | Remarks |
 |
 |
 |
||||
| LD Package | LD BAR | LD Package | ||||
| 1 | Ultrashort pulse drive | Measurement by a pulse in the order of a few tens of nanoseconds (1)Allows measurement in reliable pulse shapes close to the actual drive. |
Provided by default | Option | Provided by default |  |
| 2 | Short pulse drive | Measurement by a pulse in the order of a few microseconds (1)Outputs in the pulse shape close to the ideal shape (rectangular wave) (2)Measures the COD (*Catastrophic Optical Damage) of devices precisely. * Possibility measurement of destruction of the LD end face (light-emitting surface) |
Provided by default | Provided by default | Provided by default |  |
| 3 | CW drive (Continuous wave) |
General DC applying method | Option | Provided by default | Option |
