| Category |
Item |
Specification |
| CPU |
SoC |
QCS6490 |
| Clock Speed |
1x A78 @ 2.7 GHz, 3x A78 @ 2.4 GHz, 4x A55 @ 1.9 GHz |
| Number of CPU Cores |
8 |
| Memory |
Technology |
LPDDR5 8533MT/s |
| Max. Capacity |
Up to 8GB |
| Storage |
UFS |
Up to 128GB |
| GPU & AI |
GPU |
Adreno 643 |
| Clock Speed |
Up to 812 MHz |
| AI DSP |
Hexagon 770 |
| Clock Speed |
1.45 GHz |
| Display I/F |
LCD |
1 x eDP1.4, up to 4096 x 2160 @60Hz |
| Single Display |
Mini DisplayPort |
| Ethernet |
Controller |
i226V |
| Speed |
2.5 GbE (GH connector) |
| External I/O |
Mini DisplayPort |
1 |
| Micro SD |
1 |
| USB Type-C |
2 x USB3.2 Gen.2 (10Gbps) |
| Micro USB |
1 (for EDL only) |
| Serial Bus |
2 x I2C |
| Internal I/O |
UART |
3 x UART 3.3V |
| MIPI-CSI |
5 x 4-Lane MIPI-CSI |
| GPIO |
8-bit general purpose input output I/O |
| CANBus |
2 x CAN-FD |
| Front Panel Control |
External Power Button, and 3.3V |
| Board Feature |
Security |
Qualcomm Trusted Execution Environment (TEE) v5.3 |
| Expansion |
M.2 E-Key |
1 x E-Key 2230 (PCIe x1, USB2.0) |
| M.2 B-Key |
1 x B-Key 3052 (USB3.2 Gen1, USB 2.0) w/ Nano-SIM |
| Power |
Supply Voltage |
Vin: DC 5V-12V; RTC Battery: Lithium 3V/200mAH, support w/o CMOS Battery |
| Connector |
2-pin phoenix connector |
| Power Management |
AT, ATX |
| Max. Consumption |
17.58W (12V), 18.27W (5V) ※Ref. data. Contact FAE for adapter selection. |
| Idle Consumption |
4.88W (12V), 4.41W (5V) |
| Environment |
Temperature |
Operating: Extd: -20~70 ℃; Storage: -40~85 ℃ |
| Humidity |
Operating: 40 ℃ @95% RH; Storage: 60 ℃ @95% RH |
| Vibration Resistance |
3.5 Grms |
| Certification |
EMC |
CE, FCC Class B, ESD 8KV/15KV Criteria A |
| Mechanical |
Dimensions |
100 x 60 mm (3.9 x 2.4 in) |
| Net Weight |
50g (without Heatsink) |
| Operating system |
Linux |
Ubuntu 24.04 |
